IK10 Vandal Proof Dome Camera

IK10 - The Highest Rating for Physical Damage Protection

IK10

IK10 is the highest measurement rating for protection from physical damage for security camera products using the international standard IEC 62262 scale. IK10 is the highest rating possible, and should be protect against many human-based forms of destructive vandalism.

Realistic Expectations of IK10 Vandal Proof Protection

Most security camera manufacturer and retailers use an image of a hammer hitting a camera as a way to explain vandal proof ratings. This can be misleading.

Please don't misunderstand the scale and think that IK10 cameras are indestructible. We're happy to have gotten the highest rating possible, but want to make sure that we're not creating unrealistic expectations.

There's no ability to make a product that can never be damaged, and hitting any security camera with a hammer will almost always damage it. Technically, IK10 means that it is has survived a 20 joules impact repeated 5 times with no damage to function, in a lab and under normal environmental settings. As a point of reference, a baseball bat swing from a professional MLB player, in a normal horizontal stance, with a wooden bat, causes about a 200 joules impact on the ball. A metal bat or metal hammer has the ability to transfer even more energy if the contact area is smaller.

Although our camera has the highest rating possible, the IK10 standard isn't really as high as these "IK10 hammer" images make them appear. IK10 camera are not bomb proof, or bullet-proof, or hammer proof. No matter what other companies put on their images, if you hit their products or ours (or really anything made of glass) with a hammer or baseball bat, you probably are going to break the glass and get hurt.

Because it is the glass itself that is rated IK10, IK10 Vandal proof security cameras are obviously availible on full glass dome security cameras only.

Our vandal proof dome cameras have IK10 rated glass. IK10 is the highest rating possible for physical damage protection. This glass is also not usually availible on bullet or turret cameras, which have anti-reflection glass instead.

Cameras like our Sheriff or Judge have IK10 protection. Cameras with IK10 glass are usually installed at locations like college campuses where vandalism is common.

Our entire bullet and turret style cameras have anti-reflection glass. Anti-Reflection glass is not availible on curved glass like in traditional vandal proof dome cameras. Unless you expect a large amount of vandalism, Anti-reflection glass is the better choice, as it will give you a much better image at night. IK10 glass can have infrared light bounce back into the lens.



  1. The Sheriff 4.0 - 26DF4-IK10 - 4MP (2x1080P) Vandal Proof Fixed Wide Angle Lens IK10 Dome Camera

    In stock.
    Usually ships the same business day if ordered before 2PM EST.

    $225.00


    Resolution

    4MP UHD Quality

    4MP @ 25 FPS: 2560 x 1440

    Detect: 115 ft
    Recognize: 50 ft
    Identify: 35 ft


    Processing Power and Compression: Not All 4MP Cameras are Created Equal


    Weather

    weatherproof

    IP67
    Full protection from dust, rain, snow, dew, frost, and sprinklers.

    You can even submerge it for a few minutes.


    Temp

    temperature rating

    Temperature rated from -31°F to 140 °F

    Humidity rated between 10 and 95%.


    Lens

    fixed lens

    Fixed: 2.8mm
    101° of coverage

    Digital Zoom Only

    Learn about the 4 types of Zoom


    Day/Night

    night footage

    Infrared night vision up to 100 FT

    Color video possible until 0.02 lux

    How to get the best footage at night


    Special

    special features

    IK10 (highest possible rating) Physical Damage Protection

    True Wide Dynamic Range (120dB)

    Seeing in shadows: Understanding WDR



  2. The Judge 8.0 - 26DV8 - 4K (8MP = 4x1080P) Multi-Purpose Lens Dome Camera with Motorized Zoom and IK10

    In stock.
    Usually ships the same business day if ordered before 2PM EST.

    $799.00


    Resolution

    4K

    4K (8MP) UHD @ 30 FPS: 3840 x 2160

    Detect: up to 200 ft
    Recognize: up to 150 ft
    Identify: up to 100 ft


    4MP vs 4K


    Weather

    weatherproof

    IP67
    Full protection from dust, rain, snow, dew, frost, and sprinklers.

    You can even submerge it for a few minutes.


    Temp

    temperature rating

    Extreme Cold Temperature rated from -40°F to 140 °F

    Humidity rated between 10 and 95%.


    Lens

    varifocal lens

    Motorized Varifocal: 2.8 - 12mm
    80° - 35° of coverage

    Digital Zoom and Optical Zoom

    Fixed vs Varifocal Lenses


    Day/Night

    night footage

    Infrared night vision up to 100 FT

    Color video possible until 0.02 lux

    How to get the best footage at night


    Special

    special features

    Micro-SD Card Slot

    Alarm Inputs and Output

    Audio Input and Output

    True WDR (up to 120 dB)

    Seeing in shadows: Understanding WDR



  3. The Sheriff 8.0 - 26DF8M-IK10 - 4K (8MP = 4x1080P) Vandal Proof Fixed Wide Angle Lens IK10 Dome Camera

    In stock.
    Usually ships the same business day if ordered before 2PM EST.

    $250.00


    Resolution

    4K UHD

    4K @ 20 FPS; 3840 × 2160

    Detect: 150 ft
    Recognize: 85 ft
    Identify: 45 ft


    4MP vs 4K


    Weather

    weatherproof

    IP67
    Full protection from dust, rain, snow, dew, frost, and sprinklers.

    You can even submerge it for a few minutes.


    Temp

    temperature rating

    Temperature rated from -31°F to 140 °F

    Humidity rated between 10 and 95%.


    Lens

    fixed lens

    Fixed: 2.8mm
    112° of coverage

    Digital Zoom Only

    Learn about the Types of Zoom


    Day/Night

    night footage

    Infrared night vision up to 100 FT

    Larger image sensor for low light

    Color video possible until 0.05 lux

    How to get the best footage at night


    Special

    special features

    True 120dB Wide Dynamic Range

    IK10 Vandal Resistant

    Seeing in shadows: Understanding WDR
